Wi Fi Recorder Specification

Sensor: Starlight Night Vision 678

Image sensor: Sony Starvis 2/optional rear AHD 2K

Lens: Six sets of all glass lenses

Aperture: F1.8

Diagonal: 170 ° wide-angle

Maximum video resolution: 4K (3840 * 2160)

Encoding ability:“

Supports single channel (4K): 3840 * 2160 30fps“

Video encoding formats: H.264 encoding, H.265 encoding

Storage format: MP4/TS stream

Effective pixels: "Single recording: 8 million

Dual recording: 8 million+rear 2 million pixels“

Photo format: JPEG

Collision sensor: three-axis acceleration sensor

Recording mode: Loop recording without missing seconds

Storage: TF card (U1 or above, maximum support 256GB)

Start time: 3 seconds

Working voltage: 12V/5V

Working current: 12V "① Dual recording without screen: 240mA (12.0V); ② Single recording: 160mA (12.0V)

Static current: below 1mA

Storage temperature (℃): (-30 ℃ -80 ℃)

Operating temperature (℃): (-15 ℃ -75 ℃)

Operating humidity (℃): 15% -60% RH

Battery Type: Button Battery ML621

Wide voltage adaptive: suitable for the in car power supply environment of 5V/12V

Power off video saving: supported (MP4 format power off video restored when powered on again)

Time synchronization reminder: support (voice prompt when time is not synchronized)

Parking monitoring (time-lapse recording): Supports (protection voltage 11.8V)

OTA: Supports OTA online upgrade
